Server-Driven UI with Remote Compose

The simplest useful screen has nothing personal on it. Write it, compile it, put the bytes somewhere the app can fetch them:

fun WelcomeScreen(): ByteArray = rcDocument {    Column(Modifier.fillMaxWidth().padding(16.rdp)) {        Text("Welcome back", fontSize = 22.rsp)        Text("Your account is up to date", fontSize = 14.rsp)    }}

That's a whole screen in a couple of kbs. The app downloads it, the player draws it. Change the copy, change the layout, re-upload - every user sees the new screen on their next launch. No release, no flag, no adoption curve.

What the DSL actually writes

rcDocument is a thin wrapper. It writes a header (canvas size, density behaviour, an optional wrap-content flag), then runs your lambda against an RcScope and hands back the bytes. Every call inside that lambda appends operations to one flat buffer through a RemoteComposeWriter. There is no tree on the server. A Column is a start operation, whatever its content emitted, and an end operation.

Literals don't stay literals. A string becomes a text-data operation with an id, and the layout operation that draws it stores the id, not the characters. A dp value becomes a float expression with an id. A named slot is a name bound to an id. So a finished document is mostly a table of values followed by operations that point into it, which is exactly what makes those values replaceable later. Roughly, the welcome screen above serialises to:

Header           360 × 800, density 1, DENSITY_BEHAVIOR_PIXELS
FloatExpression  id 1 = 16 * density        ← 16.rdp, written once per document
FloatExpression  id 2 = 22 * density        ← 22.rsp
FloatExpression  id 3 = 14 * density        ← 14.rsp
Column           fillMaxWidth · padding → id 1
  TextData       id 4 = "Welcome back"
  TextLayout     text → id 4 · size → id 2
  TextData       id 5 = "Your account is up to date"
  TextLayout     text → id 5 · size → id 3
End

On the device, initFromBuffer reads the stream back and folds the start/end pairs into a component tree. setDocument then runs every data operation once (values are cached, names are registered), and the paint loop walks the tree, evaluating expressions as it goes. The tree exists only inside the player. The format is the list.

This is the entire promise, and it already works. It's also useless, because no screen worth shipping is static.

Real screens say "Welcome back, Asha". So how does Asha get into the bytes?

The obvious answer is to render the screen once per user, with her name already drawn in. But a document that belongs to one user breaks three things:

• Every launch waits on a render. The service has to be up, scaled and fast, on the critical path of opening the app.
• No shared caching. The bytes are hers, so the CDN can't hand them to anyone else and they can't be marked immutable. Her own device can keep a copy, but it dies the moment her data changes.
• One stale value costs the whole screen. Her name changed? Refetch the layout, the styling, the icons.

So Asha's name can't be in the binary. It still has to end up on the screen.

The format already has the tool for this. A document can hold named variables as well as literals: the player keeps them in a state map, draw operations point at them, and the host can set one by name at runtime. Anything prefixed USER: is a hole the host is allowed to fill.

So the server declares a hole where the value goes:

val name = remoteNamedText("USER:user.name", "")Text(name, fontSize = 22.rsp)

The client fills it after the document is playing:

player.stateUpdater.setUserLocalString("user.name", "Asha")player.invalidate()

The binary that ships is identical for everyone; it carries the empty default, not Asha. Her name travels separately, as a small JSON response from an ordinary product API, and lands in the hole at runtime. The layout is cacheable forever; the only per-user bytes on the wire are the values themselves.

What a hole is, underneath

remoteNamedText("USER:user.name", "") writes two operations: a text-data op holding the default, and a named-variable op binding the name to that op's id. Text(name) does not copy the string; it references the id. When the player loads the document it runs those data operations and builds a map from name to id.

setUserLocalString("user.name", "Asha") prepends the USER: domain, looks the name up in that map, and overrides the value behind the id. Every operation listening to that id is marked dirty and re-reads it on the next paint. No re-inflation, no layout rebuild, no new bytes: a string swapped in a table.

server   remoteNamedText("USER:user.name", "")   →  TextData id 7 = ""   +   NamedVariable "USER:user.name" → 7
         Text(name)                              →  TextLayout reads id 7

device   setUserLocalString("user.name", "Asha")
         "USER:" + "user.name"  →  name map  →  id 7  →  override  →  listeners dirty  →  repaint

Slots come in a handful of types, and each one binds wherever a literal of that type would go:

That's the whole trick. Everything below is consequences of it.

The binary is on the device with its holes empty. Something has to say which APIs fill them.

It can't be the app. Hardcode "the profile screen calls /user/details and /kyc/status" into the client and you're back to an app release every time a screen needs a new field, the exact thing this was meant to avoid.

So the screen declares its own endpoints, next to the binary that needs them, and the build publishes both into a manifest:

{  "screen": "profile",  "layoutVersion": 4,  "binary": [    {      "url": "https://cdn.example.com/prod/profile-1/9",      "sha256": "d37f6833…",      "dataEndpoints": [        { "url": "https://api.example.com/user/details", "method": "GET", "key": "user" },        { "url": "https://api.example.com/kyc/status",   "method": "GET", "key": "kyc" }      ]    }  ]}

That manifest URL is the only one the app ever constructs. Everything else it does is follow links: fetch the binary named by binary[0].url (or skip it, if that URL is already on disk), fire every dataEndpoints entry in parallel, drop the values into the holes as they land.

Which means the client knows one URL shape and no screen names. Adding a field is a server change. Pointing a screen at a different API is a server change. A brand new screen is a server change, and it appears on devices that shipped months ago.

One binary per user is solved. One binary per device isn't.

So scale it yourself. The player exposes the device's real density as a variable, and any value in the document can be an expression instead of a literal:

The format has a mode for this - set DENSITY_BEHAVIOR_DP and the player scales for you; but in these alphas it's half-built. It scales padding, offset, border, clip and spacing. It never scales explicit width or height, and never scales text. You get correct padding around fixed-size boxes with wrong-sized type in them.

Modifier.width(200.rdp).padding(16.rdp)   // emits 200 * density, 16 * densityText(fontSize = 22.rsp)

Every dp becomes value * density, resolved before layout against whatever density the device actually has. Same bytes, pixel-correct everywhere, no device metrics on the wire. Just keep the document on DENSITY_BEHAVIOR_PIXELS, or the player scales your scaled values and everything doubles.

Two artifacts, delivered independently, with nothing in common but a manifest that points at them.

Millions of users share one binary of a few kbs. A warm start costs a manifest fetch and the API calls that would have happened anyway, because the binary is already on disk.

Which raises the obvious question: if no service renders that binary per request, who renders it, and when?

A build does, once. It compiles every screen to bytes, hashes each one, uploads whatever changed, republishes the manifests and clears the CDN edge. That's an ordinary job, so it lives wherever your tests already live - Jenkins, GitHub Actions.

BUILD  (CI, on every merge to main)

  1  render every screen    Kotlin DSL ──► .rc bytes
  2  hash each section      sha256
  3  compare to live        same hash ──► reuse the URL
                            new hash  ──► freeze at a new one
  4  republish manifest     the only object that ever moves
  5  purge the CDN edge

RUNTIME  (on device, when the screen opens)

  1  GET manifest.json      the only URL the app builds
  2  GET the binary URL     skipped if it's already on disk
  3  GET data endpoints     product APIs, all in parallel
  4  parse the bytes        CoreDocument.initFromBuffer()
  5  fill the slots         setUserLocal*() then invalidate()
  6  handle taps            onNamedAction(back / link / analytics)

A designer moves a row and rewrites a label. You edit the Kotlin, open a PR, merge it.

CI renders the screen and hashes the bytes. The hash doesn't match the live manifest, so the old URL is left alone and the new bytes are frozen at a fresh one; nothing is ever overwritten.

sha256(bytes) == live manifest's sha  →  reuse the URL, upload nothing                 otherwise            →  freeze at the next free version

The manifest is repointed, the edge is purged, and that's the deploy. Whoever opens the screen next revalidates their manifest, gets a URL their device has never seen, and pulls two kbs. Everyone else pulls nothing.

Since binaries are frozen, a release is just one small mutable file; and its headers are where people get burned:

{env}/{screen}-{i}/{v}          Cache-Control: public, max-age=31536000, immutable{env}/{screen}/manifest.json    Cache-Control: no-cache, s-maxage=31536000

If you build one of these, the host integration is where you'll spend your debugging time, because the player's lifecycle has a few sharp facts that aren't obvious from the API surface:

It's alpha and it shows. Text doesn't scale in DP mode, there's no per-user gradient, lists have to be bounded, and the animation switches depend on internals that could be renamed in the next release.

None of that is the idea breaking. It's a young library, and the missing pieces are the kind you'd hope it grows into.
